Each color in the resistor has its own meaning, Electrical Calculations MOD APK helps users easily identify the exact resistance values ââbased on color. The application will provide users with four options for the number of color bands: three, four, five and six. Users need to choose the color for the four resistor bands accordingly. With the first three bands, users have 10 color options including: black, brown, red, orange, yellow, green, blue, purple, white, gray. As for the last band, the application only gives users three main colors: silver, gold and colorless. Once you have selected the color for the bands, you just need to press the calculate button, the system will immediately display the results below.Integrating many basic to advanced electrical calculation functions, Electrical Calculations Unlocked Premium will provide users with a comprehensive set of electrical calculation tools. Here, users can easily choose common calculations such as calculating wire size, current, apparent power and many other formulas. Each formula has its own calculation method and specific operations. For example, with the apparent power calculation formula, users need to choose the appropriate current, which can be direct current or alternating current. Then select the input, voltage index and current index and select the unit of measurement. With the maximum wire length calculation formula, users also need to choose the current type, voltage index, power factor, wire cross-section, parallel conductors, voltage drop, wire type, cable type and operating temperature.Not only providing normal electrical calculation formulas, Electrical Calculations MOD 10.4.3.1 also provides users with electric motor calculation formulas. Here, users will learn 16 different motor calculation formulas: motor current, motor power, motor voltage, motor power factor, motor efficiency, motor from three-phase to single-phase and some other formulas. Using motor formulas will help electrical engineers and users easily determine the necessary technical parameters during motor operation and repair. For example, with the motor calculation formula from three-phase to single-phase, users can calculate the capacitor needed to activate a three-phase motor with single-phase current. This will be a solution that brings good results with small motors, but it should be noted that with motors that must have a capacity reduction of 60-70%.Electrical Calculations MOD APK also supports users in the process of converting formulas and calculation units. Users can easily convert formulas for cross-section, length, voltage, energy, pressure and convert units such as Ah to kWh, convert Guas or Tesla. In addition, the application also provides some ready-made conversion tables such as AWG conversion, SWG conversion table and wire size comparison table according to metric or imperial measurement system. To convert formulas, users just need to enter the coefficient and select the unit they want to convert. Then press the conversion button, in just a few seconds the system will give the appropriate results. For example, you want to convert the cross-section of a wire with an index of 6 AWG, after conversion you will receive the results: wire cross-section 13.3018 mm2 and 26.2518 kcmil, diameter 4.1156 mm and 0.162 in.In addition, Electrical Calculations MOD APK also integrates a rich electrical engineering data library for users, helping users easily look up electrical information. Users can quickly find information related to items such as IEC fuses, UL/CSA fuse classes, resistivity tables, unit voltage drop tables, wire sizes and weights. In addition, the application also provides electrical networks (TT, TN, IT), IP/ICH/NEMA protection classes, Atex marking, CCTV resolution, IEC 60320 connections, Type C sockets (IEC 60309), NEMA connections, electric vehicle charging plugs, wire color codes, SI prefixes, measurement units and much more. All information is presented clearly and in detail, helping users save time looking up.Coming to Electrical Calculations MOD APK, users can also explore the electrical circuit diagram system, from household electrical diagrams to industrial electrical diagrams. Users can freely look up the pinout diagrams of ports such as RJ-45, RJ-11, USB, HDMI, VGA, DVI, FireWire, DisplayPort, PS/2. In addition, there are also specialized diagrams such as Apple Lightning, Raspberry Pi, IO-Link, MIDI, XLR, OBD II, ISO 10487 and some other diagrams. Each diagram is accompanied by clear illustrations, pin names and main functions, helping users easily identify the location and task of each pin. Download Electrical Calculations MOD APK to optimize the calculation process and look up electrical information with a specialized electrical calculator.
